ROTOR DISC » RN1322V
A PHP Error was encountered
Severity: 8192
Message: Implicit conversion from float -171.5 to int loses precision
Filename: libraries/Image_lib.php
Line Number: 1230
Specification
Type
Vented
Disc Thickness (Max)
28
Num. of holes
5
Height
47.2
Centering Diameter
64.2
Front/Rear
Front
Pitch Circle Ø
114.3
Outter Ø
299
Cross Reference
HONDA
45251-SFE-J30
HONDA
45251-SFE-J31
HONDA
45251-SLE-J30
HONDA
45251-SLE-J31
HONDA
45251-SLG-W10
| years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 02.07~08.10 | 1800 | R18A | RT1 | RN1540VRN1322V | PN8465 | RN1460 | PN8506 | FN0570 |
| 02.07~08.10 | 1800 | R18A | RT2 | RN1322V | PN8465 | RN1460 | PN8506 | FN0570 |
| 02.07~08.10 | 2000 | R20A | RT3 | RN1218VRN1322V | PN8465 | RN1460 | PN8506 | FN0570 |
| 02.07~08.10 | 2000 | R20A | RT4 | RN1322V | PN8465 | RN1460 | PN8506 | FN0570 |
| 10.03~10.08 | 2400 | K24A | RB1 | RN1322VRN1540V | PN8465 | RN1383 | PN8506 | FN8003 |
| 10.03~10.08 | 2400 | K24A | RB2 JPN | RN1322V | PN8465 | RN1383 | PN8506 | FN8003 |
| 10.08~10.13 | 2400 | K24A | RB3 | RN1540VRN1322V | PN8465 | RN1383 | PN8506 | FN8003 |
| 10.08~10.13 | 2400 | K24A | RB4 JPN | RN1322V | PN8465 | RN1383 | PN8506 | FN8003 |
| 10.08~10.13 | 2400 | K24Z | RB3 | RN1322V | PN8465 | RN1383 | PN8506 | FN8003 |
| 10.97~01.00 | 3000 | J30A | RA5 | RN1104VRN1322V | PN8254 | RN1383 | PN8397 | FN0570 |
