BRAKE SHOE » FN0540
A PHP Error was encountered
Severity: 8192
Message: Implicit conversion from float -375.5 to int loses precision
Filename: libraries/Image_lib.php
Line Number: 1230
Specification
Radius
90
Width
30
Pcs In Set
4
Thickness
6.5
Cross Reference
BENDIX EUR
362312B
FIAT
71738378
FIAT
77362297
FIAT
9945975
FIAT
9947773
| years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 09.98~05.02 | 1200 | 182 B2.000 | 182 | PN0123 | FN0540FN0593 | |||
| 09.98~05.02 | 1200 | 188 A5.000 | 182 | PN0123 | DN1710 | FN0540FN0593 | ||
| 10.95~09.98 | 1400 | 182 A3.000 | 182 | PN0123 | DN1710 | FN0540 | ||
| 10.95~12.01 | 1400 | 182 A5.000 | 182 | PN0123 | DN1710 | FN0540 | ||
| 10.95~12.01 | 1900 | 160 A7.000 | 182 | PN0123 | FN0540FN0591 |
| 08.93~08.00 | 1100 | 176 A6.000 | 176 | PN0287W | FN0517FN0540 | |||
| 08.93~08.00 | 1100 | 176 B2.000 | 176 | PN0287W | FN0517FN0540 | |||
| 05.94~04.01 | 1200 | 176 A7.000 | 176 | PN0287W | FN0517FN0540 | |||
| 10.93~04.99 | 1200 | 176 A7.000 | 176AB | PN0287W | FN0517FN0540 | |||
| 10.93~04.99 | 1200 | 176 A7.000 | 176AC | PN0287W | FN0517FN0540 | |||
| 10.93~04.99 | 1200 | 176 A7.000 | 176AR | PN0287W | FN0517FN0540 | |||
| 10.93~04.99 | 1200 | 176 A8.000 | 176AB | PN0287W | FN0517FN0540 | |||
| 10.93~04.99 | 1200 | 176 A8.000 | 176AC | PN0287W | FN0517FN0540 | |||
| 10.93~04.99 | 1200 | 176 A8.000 | 176AR | PN0287W | FN0517FN0540 | |||
| 10.93~11.96 | 1200 | 176 B1.000 | 176 | PN0235 | FN0517FN0540 | |||
| 05.94~04.01 | 1200 | 176 B4.000 | 176 | PN0287W | FN0517FN0540 | |||
| 10.93~04.99 | 1200 | 176 B4.000 | 176AB | PN0287W | FN0517FN0540 | |||
| 10.93~04.99 | 1200 | 176 B4.000 | 176AC | PN0287W | FN0517FN0540 | |||
| 10.93~04.99 | 1200 | 176 B4.000 | 176AR | PN0287W | FN0517FN0540 | |||
| 12.96~04.01 | 1200 | 176 B9.000 | 176 | PN0123 | FN0540 | |||
| 04.94~10.97 | 1600 | 176 A9.000 | 176 | PN0235 | FN0517FN0540 | |||
| 01.94~07.99 | 1700 | 176 A3.000 | 176 | PN0123PN0235 | FN0517FN0540 | |||
| 01.94~07.99 | 1700 | 176 A5.000 | 176 | PN0235 | FN0517FN0540 | |||
| 04.94~10.98 | 1700 | 176 B3.000 | 176 | PN0235PN0287W | FN0517FN0540 | |||
| 01.94~08.00 | 1700 | 176 B7.000 | 176 | PN0123PN0235 | FN0517FN0540 |
| 09.95~07.97 | 1200 | PN0235 | FN0517FN0540 | |||||
| 10.96~07.00 | 1200 | 176 B9.000 | PN0123 | FN0540 | ||||
| 09.95~09.03 | 1200 | 188 A4.000 | 840AF1A | PN0123PN0287W | FN0517FN0540 | |||
| 09.95~09.03 | 1200 | 188 A5.000 | 840AF1A | PN0123PN0287W | FN0517FN0540 | |||
| 08.97~07.00 | 1200 | 840 A3.000 | PN0123 | FN0540 | ||||
| 09.95~09.03 | 1200 | 840 A3.000 | 840AF1A | PN0123 | FN0517FN0540 | |||
| 09.95~02.98 | 1400 | 840 A2.000 | PN0123PN0235 | FN0517FN0540 | ||||
| 09.95~02.98 | 1400 | 840 A4.000 | PN0123PN0235 | FN0517FN0540 |
