ROTOR DISC » RN2148
A PHP Error was encountered
Severity: 8192
Message: Implicit conversion from float -481.5 to int loses precision
Filename: libraries/Image_lib.php
Line Number: 1230
A PHP Error was encountered
Severity: 8192
Message: Implicit conversion from float -130.5 to int loses precision
Filename: libraries/Image_lib.php
Line Number: 1230
Specification
Type
Solid
Outter Ø
314
Num. of holes
5
Disc Thickness (Max)
13
Disc Thickness (Min)
11.4
Height
60.5
Centering Diameter
69
Pitch Circle Ø
114.3
Drum Ø:
190
Structure Material
G3000
Front/Rear
Rear
Cross Reference
HYUNDAI
58411-3M300
| years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 03.16~12.20 | 2000 | G4KL | PB116 | RN2610V | PN0633 | RN2148 | PN0649PN0415 | FN0758 |
| 03.16~12.20 | 2200 | D4HC | PB116 | RN2610VRN2659V | PN0633 | RN2148 | PN0649PN0415 | FN0758 |
| 01.14~11.16 | 3000 | G6DG | GN41 | RN1711V | PN0633PN0537 | RN2148 | PN0649 | FN0758 |
| 01.14~02.17 | 3000 | G6DG | PB114 | RN2356V | PN0633 | RN2148 | PN0649 | |
| 01.08~12.14 | 3800 | G6DA | GC4D | PN0446 | RN2148 | PN0649 | FN0666 | |
| 01.14~11.16 | 3800 | G6DJ | GN41 | RN1711V | PN0633 | RN2148 | PN0649 | FN0758 |
| 01.14~11.16 | 3800 | G6DJ | PB114 US | RN1711V | PN0633 | RN2148 | PN0649 | FN0758 |
| 01.08~01.14 | 5000 | G8BE | GC4D | RN1711V | PN11002 | RN2148 | PN0649 | FN0666 |
| 01.14~11.16 | 5000 | G8BE | PB114 US | RN1715V | PN0633 | RN2148 | PN0649 | FN0758 |
| 09.11~03.18 | 3300 | G6DH | DH11 | PN0799 | RN2148 | PN0649 | ||
| 09.11~03.18 | 3800 | G6DK | DH11 | RN1711V | PN0633 | RN2148 | PN0649 |
