NiBK Brakes:: Application Cross Reference and Image for NiBK : ROTOR DISC : RN2149

ROTOR DISC » RN2149

Severity: 8192

Message: Implicit conversion from float -497.5 to int loses precision

Filename: libraries/Image_lib.php

Line Number: 1230

Severity: 8192

Message: Implicit conversion from float -158.5 to int loses precision

Filename: libraries/Image_lib.php

Line Number: 1230

Specification

Type

Solid

Outter Ø

255

Num. of holes

Disc Thickness (Max)

Disc Thickness (Min)

Height

47.6

Centering Diameter

Pitch Circle Ø

112

Drum Ø:

143.5

Front/Rear

Rear

Structure Material

G3000

Cross Reference

AUDI

4B0 615 601 B

VAG

4B0 615 601 B

years	Eng	Eng No	Body	Front Rotor	Front Brake	Rear Rotor	Rear Brake	Parking Shoe
