ROTOR DISC » RN29001V
A PHP Error was encountered
Severity: 8192
Message: Implicit conversion from float -522.5 to int loses precision
Filename: libraries/Image_lib.php
Line Number: 1230
A PHP Error was encountered
Severity: 8192
Message: Implicit conversion from float -196.5 to int loses precision
Filename: libraries/Image_lib.php
Line Number: 1230
Specification
Type
Vented
Outter Ø
272
Num. of holes
4
Disc Thickness (Max)
22
Height
40
Centering Diameter
60
Front/Rear
Front
Pitch Circle Ø
100
Drum Ø:
150
Disc Thickness (Min)
20
Structure Material
G3000
Cross Reference
SUZUKI
55311-68L50
SUZUKI
55311-71L50
SUZUKI
55311-71L51
| years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 09.10~11.16 | 1200 | K12B | ZC72S JPN | RN29001VRN2245V | PN9529 | RN1955DN1369 | FN9991PN9808 | |
| 10.09~03.13 | 1200 | K12B | ZC72S LHD | RN29001V | PN5562 | DN1369RN1955 | FN9991PN9808 | |
| 03.13~02.17 | 1200 | K12B | ZC72S LHD | RN29001V | PN5562 | RN1955DN1369 | FN9991PN9808 | |
| 09.10~01.17 | 1200 | K12B | ZD72S JPN | RN29001V | PN5562 | RN1955 | PN9808 | |
| 03.10~ | 1400 | K14B | AZG414 | RN29001V | PN5562 | RN1955RN1693DN1369 | FN9991PN9808 | |
| 03.10~ | 1400 | K14B | ZC82S LHD | RN29001VRN2245V | PN9529PN5562 | RN1955RN1693DN1369 | PN9808FN9991 | |
| 03.10~03.13 | 1400 | K14B | ZC82S RHD | RN29001V | PN5562 | RN1693RN1955DN1369 | PN9808FN9991 | |
| 03.13~02.17 | 1400 | K14B | ZC82S RHD | RN2245VRN29001V | PN9529PN5562 | RN1955DN1369RN1693 | PN9808FN9991 |
