ROTOR DISC » RN34004
A PHP Error was encountered
Severity: 8192
Message: Implicit conversion from float -500.5 to int loses precision
Filename: libraries/Image_lib.php
Line Number: 1230
A PHP Error was encountered
Severity: 8192
Message: Implicit conversion from float -178.5 to int loses precision
Filename: libraries/Image_lib.php
Line Number: 1230
Specification
Type
Solid
Outter Ø
292
Num. of holes
5
Disc Thickness (Max)
12.5
Height
45
Centering Diameter
70.7
Pitch Circle Ø
115
Front/Rear
Rear
Drum Ø:
151
Disc Thickness (Min)
10
Structure Material
G3000
Cross Reference
GM
13502137
GM
13502138
GM
13502139
GM
23118061
GM
23118282
GM
95527033
OEM
569071
OPEL
05 69 075
OPEL
05 69 099
OPEL
13504280
| years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 06.12~12.17 | 1400 | A14NET | J305 | RN34001VRN34003V | PN0391PN0757 | RN34002RN34004 | PN0392 | |
| 05.09~12.17 | 1600 | F16D4 / LDE | JA68E9 | RN34001VRN34003V | PN0391PN0757 | RN34002RN34004DN1683 | FN0665PN0392 | |
| 02.16~ | 2000 | LNP / Z20D1 | 1PU68 | RN34003V | PN0757 | RN34004 | PN0392 |
| 01.13~01.17 | 1400 | A14NET | J308 | RN34003VRN34001V | PN0391PN0757 | RN34002RN34004 | PN0392 | |
| 11.12~01.17 | 2000 | LNP / Z20D1 | 1P#35 RHD SG | RN34001VRN34003V | PN34002PN0391 | RN34002RN34004 | PN0392 |
| 03.11~12.17 | 1400 | A14NET / LUJ | YA75 | RN34003V | PN0757 | RN34004 | PN0392 | |
| 01.12~01.18 | 1600 | LVL | RPC75 | RN34003V | PN0757 | RN34004 | PN0392 | |
| 03.11~01.18 | 1800 | F18D4 (2H0) | YA75 RHD | RN34003V | PN0757 | RN34004 | PN0392 | |
| 03.11~01.18 | 1800 | F18D4 (2H0) | YF75 EU LHD | RN34003V | PN0757 | RN34004 | PN0392 | |
| 03.11~12.17 | 2000 | LNP / Z20D1 | YA75 | RN34003V | PN0757 | RN34004 | PN0392 | |
| 01.12~12.17 | 2400 | LAF | 1PK75 | RN34003V | PN0757 | RN34004 | PN0392 |
| 08.10~01.16 | 1800 | F18D4 (2H0) | KLAJA69 | RN34001VRN34003V | PN0757PN0391 | RN34002RN34004DN1683 | FN0665PN0392 | |
| 08.10~01.16 | 2000 | LNP / Z20D1 | KLAJF69 | RN34003V | PN0757 | RN34004 | PN0392 |
| 12.09~01.16 | 1400 | A14NET | J | RN34003V | PN0757 | RN34002RN34004 | PN0392 | |
| 09.09~10.15 | 1600 | A16LET | P10 | RN34003V | PN0757 | RN34004 | PN0392 | |
| 12.09~01.16 | 1600 | A16XHT | J | RN34003V | PN0757 | RN34002RN34004 | PN0392 | |
| 01.09~10.15 | 1700 | A17DT# | J | RN34001VRN34003V | PN34002PN0391 | RN34002RN34004 | PN0392 | |
| 09.12~10.15 | 1700 | A17DTC | D35 EST EU | RN34003V | PN0757 | RN34004 | PN0392 | |
| 11.09~10.15 | 2000 | A20DTH | J | RN34003V | PN0391 | RN34004 | PN0392 | |
| 10.12~10.15 | 2000 | A20DTR | J | RN34003V | PN0391 | RN34004 | PN0392 | |
| 09.09~10.15 | 2000 | Z20DTJ | E68 5DR HB | RN34003V | PN0757 | RN34004 | PN0392 |
| 03.13~01.20 | 1600 | A16XHT | W13 | RN1679V | PN34002 | RN34004 | PN0392 | |
| 01.13~06.19 | 1600 | B16SHL | W13 | RN1679V | PN34002 | RN34004 | PN0392 |
