ROTOR DISC » RN25001
A PHP Error was encountered
Severity: 8192
Message: Implicit conversion from float -494.5 to int loses precision
Filename: libraries/Image_lib.php
Line Number: 1230
Specification
Type
Solid
Outter Ø
302
Num. of holes
5
Disc Thickness (Max)
11
Height
40.8
Centering Diameter
72
Pitch Circle Ø
114.3
Front/Rear
Rear
Disc Thickness (Min)
9
Drum Ø:
152
Structure Material
G3000
Cross Reference
MAZDA
C23Y26251A
MAZDA
C26Y-26-251
MAZDA
C26Y-26-251A
| years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 07.08~05.13 | 2000 | LF-VD | CCEAW | RN1194V | PN0365 | RN25001 | PN2702 | |
| 07.08~05.13 | 2000 | LF-VD | CCEFW | RN1194V | PN0365 | RN25001 | PN2702 | |
| 06.09~05.13 | 2000 | LF-VDS | CCEFW | RN1194V | PN0365 | RN25001 | PN2702 | |
| 05.13~03.18 | 2000 | PE-VPS | CC1071 RHD | RN1194V | PN0365 | RN25001 | PN2702 | |
| 05.13~03.18 | 2000 | PE-VPS | CCFFW JPN | RN1194V | PN0365 | RN25001 | PN2702 | |
| 07.08~05.13 | 2300 | L3-VE | CC3FW | RN1194V | PN0365 | RN25001 | PN2702 |
| 06.10~08.17 | 1600 | Y6 | CW | RN1194VRN1193V | PN0365 | RN1373RN25001 | PN2702 | |
| 06.10~08.17 | 1800 | L8 | CW | RN1194VRN1193V | PN0365 | RN1373RN25001 | PN2702 | |
| 02.05~10.10 | 1800 | L823 | CR | RN1193VRN1194V | PN0365 | RN1373RN25001 | PN2702 | |
| 06.10~08.17 | 2000 | LF-VE | CW | RN1194VRN1193V | PN0365 | RN1373RN25001 | PN2702 | |
| 06.10~08.17 | 2000 | LF5H | CW | RN1194VRN1193V | PN0365 | RN1373RN25001 | PN2702 | |
| 02.05~06.10 | 2000 | LFF7 | CR | RN1194VRN1193V | PN0365 | RN25001RN1373 | PN2702 | |
| 02.05~06.10 | 2000 | LFF7 | CR19 EU LHD | RN1193VRN1194V | PN0365 | RN1373RN25001 | PN2702 | |
| 10.10~08.17 | 2000 | PE-VPS | CW | RN1194VRN1193V | PN0365 | RN25001RN1373 | PN2702 | |
| 02.05~06.10 | 2000 | RF7J | CR | RN1193VRN1194V | PN0365 | RN1373RN25001 | PN2702 | |
| 03.08~10.10 | 2300 | L3-V# | AUCV02 US | RN1193VRN1194V | PN0365 | RN25001 | PN2702 | |
| 09.04~03.08 | 2300 | L3-VE | CR | RN1193VRN1194V | PN0365 | RN1373RN25001 | PN2702 | |
| 06.10~08.17 | 2500 | L5-VE | CW | RN1194V | PN0365 | RN25001 | PN2702 |
