RN1498VR

Specification

Type
Vented
Outter Ø
334
Num. of holes
5
Disc Thickness (Max)
30
Height
50.8
Centering Diameter
62
Front/Rear
Front
Disc Thickness (Min)
27
Pitch Circle Ø
114.3
Drum Ø:
143

Variation

RN1498VL[NiBK] RN1498DSET[NiBK] RN1498VSET[NiBK]

Alternative

RN1498DSET[NiBK]

Cross Reference

TOYOTA
43512-30330
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

LEXUS   »   GS350

10.15~07.20 3500 2GR-FKS GRL16 RN1498VRRN1498VL PN1547 RN1665V PN1846 FN0699
08.05~12.11 3500 2GR-FSE GRS196 RN1498VR PN1547 RN1665V PN1494 FN0659
08.05~07.16 3500 2GR-FSE GRS196L RN1498VR PN1547 RN1665V PN1494 FN0659
