ROTOR DISC » RN1646V
A PHP Error was encountered
Severity: 8192
Message: Implicit conversion from float -129.5 to int loses precision
Filename: libraries/Image_lib.php
Line Number: 1230
Specification
Type
Vented
Outter Ø
330
Num. of holes
5
Disc Thickness (Max)
24
Height
73.3
Centering Diameter
79
Pitch Circle Ø
120
Front/Rear
Front
Disc Thickness (Min)
21,5
Drum Ø:
174
Structure Material
G3000
Cross Reference
BMW
34 11 6 764 645
BMW
34 11 6 854 999
| years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 09.06~08.10 | 3000 | N52B30A | E81 | RN1646V | PN0513 | RN1306 | PN0511 | FN0560 |
| 09.05~02.07 | 3000 | N52B30A | E87 | RN1646V | PN0513 | RN2136DSETRN1306 | PN0511 | FN0560 |
| 03.07~06.11 | 3000 | N52B30B | E87 (MUE) | RN1646V | PN0513 | RN2136DSETRN1306 | PN0511 | FN0560 |
| 03.05~01.14 | 2000 | M47D20 | E9# | RN1645VRN1646V | PN0513 | RN1306RN2383V | PN0511PN0092W | FN0560 |
| 12.04~08.07 | 2000 | M47D20(204D4) | E90 | RN1645VRN1646V | PN0513 | RN1543VRN2383V | PN0511PN0092W | FN0559 |
| 03.05~01.14 | 2000 | N47D20A | E9# | RN1398VRN1646V | PN0518PN0513 | RN1543VRN2383VRN1306 | PN0511PN0092W | FN0559FN0560 |
| 01.08~12.14 | 2000 | N47D20C | E90 | RN1398VRN1646V | PN0518PN0513 | RN1543VRN1306 | PN0511PN0092W | FN0559FN0560 |
| 03.10~ | 2000 | N47D20C | E91 | RN1398VRN1646V | PN0518PN0513 | RN1543VRN2383V | PN0092WPN0511 | FN0559FN0560 |
| 03.05~03.12 | 2500 | N52B25A | E90 | RN1398VRN1646V | PN0513PN0518 | RN1543V | PN0092WPN0511 | FN0559FN0560 |
| 03.05~03.12 | 2500 | N52B25A | E90 | RN1646VRN1398V | PN0513PN0518 | RN1543VRN2383V | PN0511PN0092W | FN0559 |
| 03.05~08.07 | 2500 | N52B25A | E92 | RN1646VRN1398V | PN0513PN0518 | RN1543V | PN0511 | FN0559 |
| 01.06~01.11 | 3000 | N53B30A | E92 | RN1646V | PN0513 | RN1543V | PN0511 | FN0559 |
| 03.05~03.12 | 3000 | N53B30A | E93 | RN1646V | PN0513 | RN1306 | PN0511 | FN0560 |
