NiBK Brakes:: Application Cross Reference and Image for NiBK : ROTOR DISC : RN1651V

ROTOR DISC » RN1651V

A PHP Error was encountered

Severity: 8192

Message: Implicit conversion from float -478.5 to int loses precision

Filename: libraries/Image_lib.php

Line Number: 1230

A PHP Error was encountered

Severity: 8192

Message: Implicit conversion from float -143.5 to int loses precision

Filename: libraries/Image_lib.php

Line Number: 1230

Specification

Type

Vented

Outter Ø

276

Num. of holes

Disc Thickness (Max)

Height

45.2

Centering Diameter

Pitch Circle Ø

114.3

Disc Thickness (Min)

22.4

Drum Ø:

137

Structure Material

G3000

Hole Ø:

10.6

Front/Rear

Front

Cross Reference

BENDIX

562228B

MITSUBISHI

MB895730

years	Eng	Eng No	Body	Front Rotor	Front Brake	Rear Rotor	Rear Brake	Parking Shoe

MITSUBISHI » Delica Space Gear

03.94~06.99	2400	4G64	PD4W	RN1651V	PN3233	RN1119	PN3280	FN0568
03.94~04.99	2500	4D56-T	PD5V	RN1651V	PN3233 PN3369	DN1338	FN6721
03.94~10.04	2800	4M40	PE8W	RN1651V	PN3233	RN1119	PN3280	FN0568
03.94~10.04	2800	4M40	PF8W	RN1651V	PN3233 PN3369	RN1119	PN3280	FN0568
03.94~10.04	2800	4M40-T	PD8W	RN1651V	PN3233	RN1119	PN3280	FN0568
03.94~01.07	3000	6G72	PD6W	RN1651V	PN3233	RN1119	PN3280	FN0568

MITSUBISHI » L400

01.95~01.01	2400	4G64	PD4V	RN1651V	PN3233	DN1338	FN6686
01.95~01.01	2400	4G64	PD4W	RN1651V	PN3233	RN1119	PN3280	FN0568
01.95~01.01	2500	4D56-T	PD5V	RN1651V	PN3233	DN1338	FN6686

MITSUBISHI » Space Gear

01.95~01.01

2400

4G64

PD4V

RN1651V

PN3233

DN1338

FN6686
