ROTOR DISC » RN1658
A PHP Error was encountered
Severity: 8192
Message: Implicit conversion from float -484.5 to int loses precision
Filename: libraries/Image_lib.php
Line Number: 1230
A PHP Error was encountered
Severity: 8192
Message: Implicit conversion from float -128.5 to int loses precision
Filename: libraries/Image_lib.php
Line Number: 1230
Specification
Type
Solid
Outter Ø
289.7
Num. of holes
5
Disc Thickness (Max)
10
Height
45.9
Centering Diameter
108.3
Front/Rear
Front
Pitch Circle Ø
139.7
Drum Ø:
183
Disc Thickness (Min)
8
Structure Material
G3000
Cross Reference
SUZUKI
5521176J00
SUZUKI
5521176J01
SUZUKI
5521176J02
| years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 10.98~ | 660 | K6A | JB23W | RN1658RN1038 | PN9118 | DN1405 | FN5524 | |
| 07.12~05.19 | 1300 | M13A | JB4# LHD | RN1658RN1038 | PN9118 | DN1405 | FN5524 | |
| 10.98~07.12 | 1300 | M13A | JB43V RHD | RN1658RN1038 | PN9118 | DN1405 | FN5524 | |
| 07.12~05.19 | 1300 | M13A | JB43V RHD | RN1658 | PN9118 | DN1405 | FN5524 | |
| 03.18~ | 1500 | K15B | JB74V LHD | RN1658 | PN9816 | FN5524 | ||
| 03.18~ | 1500 | K15B | JB74V RHD | RN1658 | PN9816 | FN5524 | ||
| 01.20~ | 1500 | K15B | JB74V RHD | RN1658 | PN9816 | FN5524 |
