ROTOR DISC » RN1660V
A PHP Error was encountered
Severity: 8192
Message: Implicit conversion from float -471.5 to int loses precision
Filename: libraries/Image_lib.php
Line Number: 1230
Specification
Type
Vented
Outter Ø
289.6
Num. of holes
5
Disc Thickness (Max)
18
Height
63.5
Centering Diameter
58.05
Front/Rear
Rear
Pitch Circle Ø
100
Structure Material
G3000
Drum Ø:
190
Cross Reference
SUBARU
26700-AJ010
SUBARU
26700-CC000
TOYOTA
SU003-10629
| years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 01.17~03.21 | 2000 | FA20C | ZC6 | RN1010VRN1122V | PN7460 | RN1529RN1660V | PN7803PN7501 | FN0755 |
| 11.11~01.17 | 2000 | FA20D | ZC6 | RN1122VRN1010V | PN7460 | RN1660VRN1529 | PN7803PN7501 | FN0755 |
| 10.21~ | 2400 | FA24C | ZD | RN1122V | PN7460 | RN1660V | PN7803 | FN0755 |
| 02.12~10.14 | 2000 | FA20 | BMG | RN1507V | PN7499 | RN1660V | PN7803 | FN0755 |
| 02.12~10.14 | 2000 | FA20E | BRG | RN1507V | PN7499 | RN1660V | PN7803 | FN0755 |
| 02.09~05.12 | 2500 | EJ25# | BM9 JPN | RN1010VRN1507V | PN7499PN7460 | RN1529RN1660V | PN7501PN7803 | FN0625 |
| 02.09~04.12 | 2500 | EJ25# | BR9 JPN | RN1122VRN1507V | PN7460PN7499 | RN1529RN1660V | PN7501PN7803 | FN0625 |
| 02.09~12.14 | 2500 | EJ255 | BM9(EURO) | RN1010VRN1507V | PN7460PN7499 | RN1529RN1660V | PN7501PN7803 | FN0625 |
| 02.09~04.12 | 2500 | EJ255 | BR9 | RN1122VRN1507V | PN7460PN7499 | RN1529RN1660V | PN7501PN7803 | FN0625 |
| 02.12~10.14 | 2500 | FB25A | BMM | RN1010VRN1122VRN1507V | PN7460PN7499 | RN1529RN1660V | PN7501PN7803 | FN0755 |
| 05.09~01.13 | 3600 | EZ36D | BMF RH | RN1507V | PN7499 | RN1660V | PN7803 | FN0625 |
