Specification
Type
Vented
Outter Ø
328
Num. of holes
5
Disc Thickness (Max)
28
Height
73
Pitch Circle Ø
120
Front/Rear
Front
Centering Diameter
75
Drum Ø:
153
Disc Thickness (Min)
26.4
Structure Material
G3000
Cross Reference
BMW
34 10 6 787 490
BMW
34106879122
| years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 04.14~08.17 | 2000 | B47D20 | Z51 LHD | RN1719V | PN0558 | RN1720V | PN0546 | |
| 04.14~08.17 | 2000 | B47D20 | Z52 RHD | RN1719V | PN0558 | RN1720V | PN0546 | |
| 09.10~08.17 | 2000 | N47D20C | F25 | RN1719V | PN0558 | RN1720V | PN0546 | |
| 06.14~10.17 | 2000 | N47D20C | WY32 JPN RHD | RN1719V | PN0558 | RN1720V | PN0546 | |
| 09.10~03.14 | 2000 | N47N | F25 | RN1719V | PN0558 | RN1720V | PN0546 |
| 04.11~08.17 | 2000 | N20B20A | F25 | RN1719V | PN0558 | RN1720V | PN0546 | |
| 06.12~08.17 | 2000 | N20B20A | F25 | RN1719V | PN0558 | RN1720V | PN0546 |
| 08.11~08.17 | 2000 | N20B20A | F25 | RN1719V | PN0558 | RN1720V | PN0546 | |
| 04.12~08.17 | 2000 | N20B20A | F25 | RN1719V | PN0558 | RN1720V | PN0546 | |
| 01.11~10.12 | 3000 | N52B30A | F25 | RN1719V | PN0558 | RN1720V | PN0546 |
