ROTOR DISC » RN1783V
A PHP Error was encountered
Severity: 8192
Message: Implicit conversion from float -120.5 to int loses precision
Filename: libraries/Image_lib.php
Line Number: 1230
Specification
Type
Vented
Outter Ø
320
Num. of holes
5
Disc Thickness (Max)
24
Height
58.2
Centering Diameter
67
Pitch Circle Ø
112
Disc Thickness (Min)
21.4
Cross Reference
MERCEDES-BENZ
A 221 423 04 12
MERCEDES-BENZ
A 221 423 10 12
MERCEDES-BENZ
A 221 423 10 12 07
| years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 02.11~12.13 | 4700 | M 278.920 | C216 | RN1835DSETRN1782DSET | PN0857PN0453W | RN1783V | PN0344W | FN0657 |
| 06.06~01.11 | 5500 | M 273.961 | C216 | RN1782DSET | PN0453W | RN1783V | PN0344W | FN0657 |
| 05.06~12.13 | 5500 | M 275.953 | C216 | RN1835DSETRN1782DSET | PN31012PN0453W | RN1783V | PN0343PN0344W | FN0657 |
| 01.11~12.13 | 2200 | OM 651.961 | W221 | RN1782DSET | PN0453W | RN1783V | PN0344W | FN0657 |
| 08.06~12.13 | 3000 | M 272.946 | W221 | RN1782DSET | PN0453W | RN1783V | PN0344W | FN0657 |
| 12.05~06.09 | 3000 | OM 642.930 | W221 | RN1782DSET | PN0453W | RN1783V | PN0344W | FN0657 |
| 01.07~12.13 | 3000 | OM 642.932 | W221 | RN1782DSET | PN0453W | RN1783V | PN0344W | FN0657 |
| 05.05~12.09 | 3500 | M 272.965 | V221 | PN0453W | RN1783V | PN0344W | FN0657 | |
| 01.05~11.10 | 3500 | M 272.965 | W221 | RN1782DSET | PN0453W | RN1783V | PN0344W | FN0657 |
| 11.10~12.13 | 3500 | M 276.950 | W221 | RN1782DSET | PN0453W | RN1783V | PN0344W | FN0657 |
| 01.05~11.10 | 3500 | M 272.965 | W221 | RN1782DSET | PN0453W | RN1783V | PN0344W | FN0657 |
| 11.09~10.13 | 3500 | M 272.965 | W221 | RN1782DSET | PN0453W | RN1783V | PN0344W | FN0657 |
| 12.06~07.09 | 4000 | OM 629.911 | W221 | RN1782DSET | PN0453W | RN1783V | PN0344W | FN0657 |
| 12.05~12.13 | 4700 | M 273 | W221 | RN1782DSET | PN0453W | RN1783V | PN0344W | FN0657 |
| 11.10~12.13 | 4700 | M 278.932 | W221 | RN1835DSETRN1782DSET | PN0857PN0453W | RN1783V | PN0344W | FN0657 |
| 01.05~12.10 | 5500 | M 273.961 | W221 | RN1782DSET | PN0453W | RN1783V | PN0344W | FN0657 |
| 12.05~12.13 | 5500 | M 275.953 | W221 | RN1782DSETRN1835DSET | PN0453WPN0341WPN31012 | RN1783V | PN0344WPN0343 | FN0657 |
| 03.06~01.12 | 5500 | M 273.965 | R230 | RN1782DSET | PN0453W | RN1783V | PN0344W | FN0657 |
