ROTOR DISC » RN1856
A PHP Error was encountered
Severity: 8192
Message: Implicit conversion from float -484.5 to int loses precision
Filename: libraries/Image_lib.php
Line Number: 1230
A PHP Error was encountered
Severity: 8192
Message: Implicit conversion from float -128.5 to int loses precision
Filename: libraries/Image_lib.php
Line Number: 1230
Specification
Type
Solid
Outter Ø
290
Num. of holes
5
Disc Thickness (Max)
12
Height
44
Centering Diameter
71.1
Pitch Circle Ø
108
Front/Rear
Rear
Disc Thickness (Min)
10
Drum Ø:
136
Structure Material
G3000
Hole Ø:
13.3
Cross Reference
PEUGEOT
4249.G2
| years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 11.10~09.18 | 1600 | DV6C | 4-Sedan | RN2672VRN1896VRN2160V | PN0563WPN42001WPN0462W | RN1856RN2645 | PN2702PN0473 | |
| 08.14~11.18 | 1600 | DV6FC | 4-Sedan | RN1896VRN2160V | PN0563WPN42001W | RN1856 | PN2702 | |
| 11.10~09.18 | 1600 | EP6CDT | 8D | RN2160V | PN0462W | RN1856 | PN2702 | |
| 11.10~09.18 | 1600 | EP6CDT 156PH | 4-Sedan | RN2160VRN2672VRN1896V | PN0462WPN42001WPN0563W | RN1856RN2645 | PN2702PN0473 | |
| 08.14~06.18 | 1600 | EP6CDT M 163PH | 4-Sedan | RN2160VRN1896VRN2672V | PN0563WPN0462WPN42001W | RN2645RN1856 | PN0473PN2702 | |
| 08.14~11.18 | 1600 | EP6FDT | 4-Sedan | RN2160V | PN0462W | RN1856RN2645 | PN2702PN0473 | |
| 11.10~08.18 | 2000 | DW10BTED4 | 508 | RN1896V | PN0563W | RN1856 | PN2702 | |
| 11.10~09.18 | 2000 | DW10CTED4 | RXH | RN2672V | PN42001W | RN2645RN1856 | PN0473PN2702 | |
| 11.10~09.18 | 2200 | DW12C | 4-Sedan | RN2672VRN1896V | PN42001WPN0563W | RN2645RN1856 | PN2702PN0473 |
| 11.10~11.18 | 1600 | DV6C | 5-Hatchback | RN2160VRN1896VRN2672V | PN0563WPN0462W | RN1856RN2645 | PN2702PN0473 | |
| 03.14~01.19 | 1600 | DV6FC | WGN EU LHD | RN1896V | PN0563W | RN1856 | PN2702 | |
| 11.10~09.18 | 1600 | EP6CDT 156PH | 5-Hatchback | RN2160VRN2672VRN1896V | PN0462WPN42001WPN0563W | RN1856RN2645 | PN2702PN0473 | |
| 11.10~11.18 | 1600 | EP6FDT | 5-Hatchback | RN2160VRN1896VRN2672V | PN0462WPN0563W | RN1856RN2645 | PN2702PN0473 | |
| 11.10~09.18 | 2200 | DW12C | 5-Hatchback | RN2672V | PN42001W | RN2645RN1856 | PN2702PN0473 |
