ROTOR DISC » RN1877V
A PHP Error was encountered
Severity: 8192
Message: Implicit conversion from float -480.5 to int loses precision
Filename: libraries/Image_lib.php
Line Number: 1230
A PHP Error was encountered
Severity: 8192
Message: Implicit conversion from float -121.5 to int loses precision
Filename: libraries/Image_lib.php
Line Number: 1230
Specification
Type
Vented
Outter Ø
296
Num. of holes
5
Disc Thickness (Max)
28
Height
44
Centering Diameter
68
Pitch Circle Ø
114.3
Cross Reference
FIAT
6000619994
GM
93866700
NISSAN
40206-00Q1C
OPEL
4 422 285
RENAULT
40 20 663 52R
| years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 03.20~05.22 | 1600 | R9M | VH16S | RN1877V | PN0729 | RN2413H | PN0147 | |
| 03.20~05.22 | 2000 | M9R | VH20L | RN1877V | PN0729 | RN2413H | PN0147 | |
| 03.20~05.22 | 2000 | M9R | VH20S | RN1877V | PN0729 | RN2413H | PN0147 |
| 06.14~ | 1600 | R9M 408 | FGMD | RN1877V | PN0729 | RN2413H | PN0147 | |
| 06.14~09.19 | 1600 | R9M 450 | FGMA EU | RN1877V | PN0729 | RN2413H | PN0147 | |
| 06.14~ | 1600 | R9M 450 | FGMC | RN1877V | PN0729 | RN2413H | PN0147 | |
| 06.14~06.19 | 1600 | R9M 452 | FGMC | RN1877V | PN0729 | RN2413H | PN0147 | |
| 06.14~06.19 | 1600 | R9M 452 | JGMH | RN1877V | PN0729 | RN2413H | PN0147 | |
| 05.21~ | 2000 | M9R 717 | JGMW VAN EU | RN1877V | PN0729 | RN2413H | PN0147 |
