RN1914

Specification

Type
Solid
Outter Ø
324
Num. of holes
6
Disc Thickness (Max)
12
Height
69.5
Centering Diameter
96.3
Pitch Circle Ø
139.6
Drum Ø:
210
Front/Rear
Rear
Structure Material
G3000
Disc Thickness (Min)
10.4
Hole Ø:
12.5

Cross Reference

KIA
58411-4D000
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

KIA   »   Carnival / Sedona 06

01.10~11.14 2200 D4HB WAGON LONG - 11P RN2609V PN0588 RN1914 PN0457 FN0689
09.05~10.06 2900 J3 K4D005 RN1915V PN0458 RN1914 PN0457 FN0689
11.06~10.14 2900 J3 WAGON LONG - 11P RHD RN2609V PN0588 RN1914 PN0457 FN0689
11.06~01.14 2900 J3 WAGON LONG - 8P RN1915V PN0588PN0458 RN1914 PN0457 FN0689
01.06~01.14 3500 G6DC WAGON LONG - 8P RN1915V PN0458 RN1914 PN0457 FN0689
09.05~10.06 3800 G6DA D005 LONG RN1915V PN0458 RN1914 PN0457 FN0689
