ROTOR DISC » RN1917V
A PHP Error was encountered
Severity: 8192
Message: Implicit conversion from float -88.5 to int loses precision
Filename: libraries/Image_lib.php
Line Number: 1230
Specification
Type
Vented
Outter Ø
326
Num. of holes
5
Disc Thickness (Max)
20
Height
38
Centering Diameter
64.5
Pitch Circle Ø
108
Drum Ø:
160.4
Front/Rear
Rear
Disc Thickness (Min)
18
Structure Material
G3000
Cross Reference
JAGUAR
C2C 25339
JAGUAR
C2D 26352
JAGUAR
C2D 61075
| years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 01.11~05.15 | 2000 | 204PT | X250 | RN1916VRN1918V | PN0462WPN0683W | RN1917V | PN2702 | |
| 09.11~03.16 | 2200 | 224DT | CC9 | RN1916V | PN0462WPN0683W | RN1917V | PN2702 | |
| 01.08~05.11 | 2200 | 224DT | X250 | RN1916V | PN0462W | RN1917V | PN2702 | |
| 04.11~04.15 | 2200 | 224DT | X250 | RN1916V | PN0462W | RN1917V | PN2702 | |
| 01.08~05.11 | 3000 | 306DT | X250 | RN1918V | PN0683W | RN1917V | PN2702 | |
| 06.11~05.15 | 3000 | 306DT | X250 | RN1918V | PN0683W | RN1917V | PN2702 | |
| 03.11~05.15 | 3000 | AJ126 | X250 | RN1918V | PN0683W | RN1917V | PN2702 | |
| 03.08~04.15 | 3000 | AJ30 | C05D | RN1916V | PN0462W | RN1917V | PN2702 | |
| 03.08~04.11 | 3000 | AJ30 | C06D | RN1916V | PN0462W | RN1917V | PN2702 | |
| 01.08~04.11 | 3000 | AJ30 | X250 | RN1916V | PN0462W | RN1917V | PN2702 | |
| 03.08~04.15 | 5000 | AJ133/508PN | CC9 | RN1918V | PN0683W | RN1917V | PN2702 |
| 01.15~ | 2000 | 4PT | X351 | RN1918V | PN0683W | RN1917V | PN2702 | |
| 07.09~ | 3000 | 306DT | X351 | RN1918V | PN0683W | RN1917V | PN2702 | |
| 01.11~12.15 | 3000 | AJ126 | X351 | RN1918V | PN0683W | RN1917V | PN2702 | |
| 01.03~12.10 | 3000 | AJV6 | X350 | RN1916V | PN0462W | RN1917V | PN2702 | |
| 10.09~08.19 | 5000 | AJ133/508PN | X351 | RN1918V | PN0683W | RN1917V | PN2702 |
| 05.12~08.17 | 2000 | 204PT | X351 | RN1918V | PN0683W | RN1917V | PN2702PN0721 | |
| 05.12~ | 3000 | AJ126 | X351 | RN1918V | PN0683W | RN1917V | PN2702 | |
| 05.04~05.09 | 3000 | AJ30 | X350 | RN1916V | PN0683W | RN1917V | PN2702 |
| 01.06~01.09 | 4200 | AJ40 | C44P | RN1916V | PN0462W | RN1917V | PN2702 | |
| 01.06~01.15 | 4200 | AJ40 | XK | RN1916V | PN0462WPN0683W | RN1917V | PN2702 | |
| 03.06~07.14 | 4200 | AJ40K (SV8TS) | XK | RN1918V | PN0683WPN0483 | RN1917V | PN2702 | |
| 02.09~03.11 | 5000 | AJ133/508PN | AC46F | RN1918V | PN0683W | RN1917V | PN2702 |
