Specification
Type
Vented
Outter Ø
249.2
Num. of holes
5
Disc Thickness (Max)
18
Height
44
Centering Diameter
64
Pitch Circle Ø
114.3
Disc Thickness (Min)
16
Drum Ø:
139
Structure Material
G3000
Front/Rear
Front
Hole Ø:
12.7
Cross Reference
SUZUKI
55311-61J01
SUZUKI
55311-61J01-000
| years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 11.07~ | 1500 | G15A# | GC415V-2 DN41V | RN1934V | PN1847PN1832 | DN1414 | FN9980FN9803 | |
| 01.06~ | 1600 | G16A | GC416G LHD PR | RN1934V | PN1832PN1847 | FN9803FN9980 | ||
| 01.13~01.19 | 1600 | G16A | GC416V-2 | RN1934V | PN1832PN1847 | DN1414 | FN9980 | |
| 01.04~01.08 | 1600 | G16AID | GC416V | RN1934V | PN1832PN1847 | DN1414 | FN9803FN9980 | |
| 01.13~01.19 | 1600 | G16AID | GC416V LHD | RN1934V | PN1832PN1847 | FN9803FN9980 | ||
| 01.08~ | 1600 | G16AID | GC416V RHD | RN1934V | PN1832PN1847 | DN1414 | FN9980FN9803 | |
| 01.19~ | 1600 | G16AID | GC416V-4 RHD FOURGON | RN1934V | PN1832 | FN9980 |
