ROTOR DISC » RN1943
A PHP Error was encountered
Severity: 8192
Message: Implicit conversion from float -471.5 to int loses precision
Filename: libraries/Image_lib.php
Line Number: 1230
A PHP Error was encountered
Severity: 8192
Message: Implicit conversion from float -132.5 to int loses precision
Filename: libraries/Image_lib.php
Line Number: 1230
Specification
Type
Solid
Outter Ø
286
Num. of holes
5
Disc Thickness (Max)
10
Height
64.9
Centering Diameter
62
Pitch Circle Ø
114.3
Front/Rear
Rear
Drum Ø:
190
Disc Thickness (Min)
8.5
Structure Material
G3000
Hole Ø:
14.5
Cross Reference
TOYOTA
42431-06130
| years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 01.06~09.11 | 2400 | 2AZ-FE | ACV40L | RN1241V | PN1521PN0828 | RN1432RN1943 | PN1522PN0829 | FN0633FN0675 |
| 01.06~07.12 | 2400 | 2AZ-FE | ACV40R | RN1241V | PN1521PN0828 | RN1432RN1943 | PN1522PN0829 | FN0675 |
| 09.11~09.17 | 3500 | 2GR-FE | GSV50L | RN1241V | PN0828PN1521 | RN1943RN1432 | PN0829PN1522 | FN0633 |
| 08.11~10.17 | 2500 | 2AR-FE | ASV50L | RN1241V | PN0828PN1521 | RN1943RN1432 | PN0829PN1522 | FN0633FN0675 |
| 10.11~10.17 | 2500 | 2AR-FE | ASV50R | RN1241V | PN0828PN1521 | RN1943 | PN0829PN1522 | FN0633FN0675 |
| 01.06~10.11 | 3500 | 2GR-FE | GSV40L | RN1241V | PN1521PN0828 | RN1432RN1943 | PN1522PN0829 | FN0633 |
| 10.06~10.11 | 3500 | 2GR-FE | GSV40R | RN1241V | PN1521PN0828 | RN1943 | PN1522PN0829 | FN0633FN0675 |
| 01.12~10.17 | 3500 | 2GRFE | GSV50 | RN1241V | PN0828PN1521 | RN1943 | PN0829PN1522 |
