ROTOR DISC » RN1982V
A PHP Error was encountered
Severity: 8192
Message: Implicit conversion from float -477.5 to int loses precision
Filename: libraries/Image_lib.php
Line Number: 1230
A PHP Error was encountered
Severity: 8192
Message: Implicit conversion from float -143.5 to int loses precision
Filename: libraries/Image_lib.php
Line Number: 1230
Specification
Type
Vented
Outter Ø
276
Num. of holes
5
Disc Thickness (Max)
26
Height
45.4
Centering Diameter
60
Front/Rear
Front
Pitch Circle Ø
105
Disc Thickness (Min)
24
Drum Ø:
139
Structure Material
G3000
Cross Reference
GM
13515905
GM
13597459
GM
13597460
HOLDEN
13515908
OPEL
13515906
| years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 01.16~02.21 | 149KW | 1FB48 | RN1982V | PN52009 | RN1983 | PN0712 | ||
| 05.21~ | 1ET25 | 1F#48 | RN1982V | PN52009 | RN1983 | PN0712 |
| 11.15~ | 1000 | B10XFL | E35 EST | RN1982V | PN34002PN0713 | RN1983 | PN0712 | |
| 11.15~ | 1000 | B10XFL | E68 | RN1982V | PN0713 | RN1983 | PN0712 | |
| 11.15~ | 1000 | B10XFL | E68 5DR HB | RN1982V | PN0713 | RN1983 | PN0712 | |
| 09.15~12.22 | 1400 | B14XFT | B16 | RN1982V | PN0713PN34002 | RN1983 | PN0712 | |
| 10.15~04.19 | 1400 | D14XFL | 0BD68 | RN1680VRN1982V | PN34003PN0713 | RN1983 | PN0712 | |
| 08.19~12.22 | 1400 | F14SHT / L3T | VBE6 E68 HB RHD | RN1680VRN1982V | PN34003PN0713 | RN1983 | PN0712 | |
| 09.19~ | 1500 | F15DV# | B16 | RN1982VRN1680V | PN0713PN34003 | RN1983 | PN0712 | |
| 06.15~ | 1600 | B16DTE | B16 | RN1982V | PN0713PN34002 | RN1983 | PN0712 | |
| 07.17~04.19 | 1600 | B16SHT | B16 | RN1982V | PN0713 | RN1983 | PN0712 | |
| 01.16~12.21 | 1600 | D16DTN | 0BD68 | RN1982V | PN34002PN0713 | RN1983 | PN0712 |
