ROTOR DISC » RN2034V
A PHP Error was encountered
Severity: 8192
Message: Implicit conversion from float -501.5 to int loses precision
Filename: libraries/Image_lib.php
Line Number: 1230
A PHP Error was encountered
Severity: 8192
Message: Implicit conversion from float -164.5 to int loses precision
Filename: libraries/Image_lib.php
Line Number: 1230
Specification
Type
Vented
Outter Ø
256
Num. of holes
4
Disc Thickness (Max)
20
Height
45
Centering Diameter
64
Pitch Circle Ø
100
Disc Thickness (Min)
18.4
Drum Ø:
125
Structure Material
G3000
Hole Ø:
12.5
Front/Rear
Front
Cross Reference
MITSUBISHI
MR569931
MITSUBISHI
MR569932
| years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 10.04~07.12 | 1300 | 4A90 | Z21A | RN2034V | PN3500 | DN1340DN1356 | FN1267FN6729 | |
| 10.02~11.04 | 1300 | 4G19 | Z25A | RN2034V | PN3500 | DN1340 | FN6729 | |
| 10.02~10.04 | 1300 | 4G19 | Z26A | RN2034V | PN3500 | DN1340 | FN6729 | |
| 10.04~06.10 | 1500 | 4A91 | Z23A | RN2034V | PN3500 | DN1340DN1356 | FN1267FN6729 | |
| 10.02~06.12 | 1500 | 4A91 | Z24A | RN2034V | PN3500 | DN1340 | FN6729 | |
| 01.03~10.11 | 1500 | 4G15T | Z27A | RN2034V | PN3500 | DN1340 | FN6729 | |
| 06.03~11.04 | 1500 | 4G15T | Z27A | RN1944VRN2034V | PN3126PN3462PN3500 | RN1923DN1340 | PN3314PN3593FN6729 |
