ROTOR DISC » RN1795V
A PHP Error was encountered
Severity: 8192
Message: Implicit conversion from float -477.5 to int loses precision
Filename: libraries/Image_lib.php
Line Number: 1230
Specification
Type
Vented
Outter Ø
300
Num. of holes
5
Disc Thickness (Max)
22
Height
57.5
Centering Diameter
67
Pitch Circle Ø
112
Drum Ø:
164
Front/Rear
Rear
Cross Reference
MERCEDES-BENZ
A 000 423 12 12
MERCEDES-BENZ
A 204 423 07 12
| years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 01.07~01.14 | 3000 | OM 642.960 | W204 | RN1705VRN1464V | PN0395W | RN1795V | PN0460W | FN0672 |
| 08.07~08.14 | 3200 | OM 642.960 | S204 | RN1705VRN1464V | PN0395W | RN1795V | PN0460W | FN0672 |
| 08.07~08.14 | 3500 | M 272.961 | S204 | RN1705VRN1464V | PN0395W | RN1795V | PN0460W | FN0672 |
| 01.07~01.14 | 3500 | M 272.961 | W204 | RN1464VRN1464DSETRN1705V | PN0395W | RN1795V | PN0460W | FN0672 |
| 06.11~08.14 | 3500 | M 276.957 | S204 | RN1705VRN1464V | PN0395W | RN1795V | PN0460W | FN0672 |
| 03.11~01.14 | 3500 | M 276.957 | W204 | RN1464VRN1705V | PN0395W | RN1795V | PN0460W | FN0672 |
| 06.11~06.13 | 3000 | OM 642.838 | 207.323 | RN1464V | PN0395W | RN1795V | PN0460W | FN0672 |
| 01.09~12.11 | 3500 | M 272.983 | C207 | RN1705VRN1464V | PN0395W | RN1795V | PN0460W | FN0672 |
| 01.10~12.14 | 3500 | M 272.984 | A207 | RN1464VRN1705V | PN0395W | RN1795V | PN0460W | FN0672 |
| 01.09~12.11 | 3500 | M 272.984 | C207 | RN1464DSET | PN0395W | RN1795V | PN0460W | FN0672 |
| 01.10~12.11 | 3500 | M 272.988 | C207 | RN1464V | PN0395W | RN1795V | PN0460W | FN0672 |
| 04.11~12.14 | 3500 | M 276.957 | A207 | RN1464VRN1705V | PN0395W | RN1795V | PN0460W | FN0672 |
| 01.13~05.17 | 3500 | M 276.957 | C207 | RN1464VRN1705V | PN0395W | RN1795V | PN0460W | FN0672 |
| 06.13~12.16 | 3000 | M 276.820 | A207 | RN1464DSETRN2466DRN1705V | PN0395W | RN1795V | PN0460W | FN0672 |
| 06.13~12.16 | 3000 | M 276.820 | C207 | RN1464DSETRN2466DRN1705V | PN0395W | RN1795V | PN0460W | FN0672 |
| 09.11~12.16 | 4700 | M 278.922 | A207 | RN1835DSETRN2466D | PN0556WPN0556 | RN1795V | PN0460W | FN0672 |
| 09.11~12.16 | 4700 | M 278.922 | C207 | RN1835DSETRN2466D | PN0556WPN0395WPN0556 | RN1795V | PN0460W | FN0672 |
| 01.09~09.11 | 5500 | M 273.966 | C207 | RN2466D | PN0395W | RN1795V | PN0460W | FN0672 |
| 01.10~12.11 | 5500 | M 273.971 | A207 | RN2466D | PN0395W | RN1795V | PN0460W | FN0672 |
