RN2054V

Specification

Type
Vented
Outter Ø
260
Num. of holes
5
Disc Thickness (Max)
23
Height
47
Centering Diameter
64.1
Pitch Circle Ø
114.3
Drum Ø:
141.3
Front/Rear
Front
Structure Material
G3000
Hole Ø:
12.5
Disc Thickness (Min)
21

Cross Reference

HONDA
45251-S30-000
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

HONDA   »   CR-V

01.97~01.01 2000 B20B RD2 JPN RN2054V PN8484 DN1379 FN5524
09.01~08.04 2000 K20A RD4 JPN RN2054V PN8484 RN1460 PN8807 FN0570
09.01~08.04 2000 K20A RD5 JPN RN1177VRN2054VRN1218V PN8484PN8485 RN1460 PN8807 FN0570
11.01~01.05 2000 K20A RD5 RHD RN1177VRN2054V PN8485PN8484 RN1460 PN8397PN8807 FN8003FN0570
11.04~01.05 2000 K20A RD5 RHD KU RN2054VRN1177V PN8484PN8485 RN1460RN1259 PN8397PN8807 FN0570FN8003
