ROTOR DISC » RN2089
A PHP Error was encountered
Severity: 8192
Message: Implicit conversion from float -497.5 to int loses precision
Filename: libraries/Image_lib.php
Line Number: 1230
A PHP Error was encountered
Severity: 8192
Message: Implicit conversion from float -151.5 to int loses precision
Filename: libraries/Image_lib.php
Line Number: 1230
Specification
Type
Solid
Outter Ø
272
Num. of holes
5
Disc Thickness (Max)
10
Disc Thickness (Min)
8
Height
48.2
Centering Diameter
65
Pitch Circle Ø
100
Drum Ø:
140
Structure Material
G3000
Cross Reference
AUDI
6R0 615 601 B
VAG
6R0 615 601
VAG
6R0 615 601 B
| years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 01.16~10.18 | 1000 | CHZE | 3DR/5DR HB | RN1116VRN1082VRN1379V | PN0348WPN0148W | RN1084RN2089 | PN0624PN0019W | |
| 03.13~04.15 | 1400 | CPTA | 3DR/5DR HB | RN1377V | PN0348W | RN2089 | PN0019W | |
| 11.14~10.18 | 1400 | CUSB | 3DR/5DR HB | RN1379VRN1082VRN1116V | PN0348WPN0148W | RN2089RN1084 | PN0019WPN0624 | |
| 11.14~10.18 | 1400 | CZEA | 3DR/5DR HB | RN1379VRN1082VRN1116V | PN0148WPN0348W | RN1084RN2089 | PN0019WPN0624 | |
| 05.10~04.15 | 1600 | CAYC | 3DR/5DR HB | RN1379V | PN0348WPN0148W | RN2089 | PN0019W | |
| 11.14~10.18 | 1600 | CXMA | 3DR/5DR HB | RN1116VRN1082VRN1379V | PN0348WPN0148W | RN2089RN1084 | PN0624PN0019W | |
| 02.15~10.18 | 1800 | DAJB | 3DR/5DR HB | RN1379VRN1116V | PN0348W | RN2089RN1084 | PN0624PN0019W | |
| 03.12~11.12 | 2000 | CDLH | 3DR/5DR HB | RN1377V | PN0348WPN0148W | RN2089RN33004 | PN0019W |
