ROTOR DISC » RN1204V
A PHP Error was encountered
Severity: 8192
Message: Implicit conversion from float -511.5 to int loses precision
Filename: libraries/Image_lib.php
Line Number: 1230
A PHP Error was encountered
Severity: 8192
Message: Implicit conversion from float -189.5 to int loses precision
Filename: libraries/Image_lib.php
Line Number: 1230
Specification
Type
Vented
Disc Thickness (Max)
25
Num. of holes
5
Height
47.1
Centering Diameter
64.1
Pitch Circle Ø
114.3
Front/Rear
Front
Outter Ø
300
Drum Ø:
141
Disc Thickness (Min)
23
Structure Material
G3000
Cross Reference
HONDA
45251-SEA-E30
| years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 10.02~10.05 | 2000 | K20Z | CL7 LHD | RN1204VRN1405V | PN8125 | RN1203 | PN8109 | |
| 10.05~12.08 | 2000 | K20Z | CL7 LHD | RN1204VRN1405V | PN8125 | RN1203 | PN8109 | |
| 10.05~12.08 | 2000 | K20Z | CL7 RHD | RN1204V | PN8125 | RN1203 | PN8109 | |
| 06.06~12.08 | 2000 | K20Z2 | EURO | RN1218VRN1204V | PN8485PN8125 | RN1203 | PN8398PN8109 | |
| 01.04~05.08 | 2200 | N22A1 | CN1 LHD | RN1204V | PN8125 | RN1203 | PN8109 | |
| 01.04~06.08 | 2200 | N22A1 | CN1 RHD | RN1204V | PN8125 | RN1203 | PN8109 | |
| 09.09~06.15 | 2200 | N22B1/2 | EURO | RN1406VRN1204V | PN8863PN8865 | RN1407 | PN8807 | FN0663 |
| 10.02~12.08 | 2400 | K24A | CL9 JPN | RN1204VRN1413V | PN8125PN8465 | RN1203 | PN8398PN8109 | |
| 10.02~10.05 | 2400 | K24A3 | CL9 LHD | RN1413VRN1204V | PN8465PN8125 | RN1203 | PN8109PN8398 | |
| 10.05~12.08 | 2400 | K24A3 | CL9 LHD | RN1204V | PN8125 | RN1203 | PN8109 | |
| 10.02~12.08 | 2400 | K24A3 | CL9 RHD | RN1204VRN1413V | PN8465PN8125 | RN1203 | PN8109PN8398 | |
| 11.05~12.08 | 2400 | K24A8 | CM5 RHD | RN1218VRN1204V | PN8465 | RN1203 | PN8398 |
| 01.06~12.08 | 2000 | K20Z2 | EURO | RN1204VRN1405V | PN8125 | RN2156 | PN8398 | FN0570 |
| 04.03~12.08 | 2200 | N22A1 | CN2 | RN1204V | PN8125 | RN2156 | PN8397 | FN0570 |
| 01.04~12.08 | 2200 | N22A1 | CN2 | RN1204V | PN8125 | RN2156 | PN8397 | |
| 03.03~12.08 | 2400 | K24A3 | EURO | RN1204V | PN8125 | RN2156 | PN8397 | FN0663 |
| 01.09~12.10 | 2400 | K24Z3 | EURO | RN1204V | PN8125 | RN2156 | PN8397 | FN0570 |
