BRAKE PADS » PN8109
A PHP Error was encountered
Severity: 8192
Message: Implicit conversion from float -196.5 to int loses precision
Filename: libraries/Image_lib.php
Line Number: 1230
Specification
Length-1
87.2
Width-1
53
Thickness-1
15
Pcs In Set
4
Brake System
TRW
Cross Reference
BENDIX EUR
572478B
FMSI
D1973-9200
HONDA
43022-S1A-E02
HONDA
43022-S1A-E03
HONDA
43022-S1A-E04
HONDA
43022-S1A-E30
HONDA
43022-S1A-E50
HONDA
43022-SEA-E01
HONDA
43022-SEA-E10
KASHIYAMA
D5109
| years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 01.99~01.03 | 1600 | D16B6 | CH5 | RN1093V | PN8106PN8526 | PN8109FN28001 | ||
| 01.98~12.02 | 1800 | F18B2 | CG8 | RN1137V | PN8106 | PN8109 | ||
| 01.98~06.02 | 1800 | F18B2 | CH6 | RN1248V | PN8106 | PN8109 | ||
| 01.98~01.03 | 1800 | F18B2 | CK | RN1137V | PN8106 | PN8109 | ||
| 10.98~12.02 | 2000 | 20T | EURO | RN1137V | PN8106 | PN8109 | ||
| 10.98~12.02 | 2000 | 20T2N | CH8 | RN1137V | PN8106 | PN8109 | ||
| 01.98~10.02 | 2000 | F20B6 | CG2 | RN1248V | PN8106 | PN8109 | ||
| 01.98~01.01 | 2000 | F20B6 | CG9 LHD | RN1137V | PN8106 | PN8109 | ||
| 01.99~06.00 | 2000 | F20B6 | EURO | RN1137V | PN8106 | PN8109 | ||
| 10.02~10.05 | 2000 | K20A6 | CL7 RHD | RN1405V | PN8125 | RN1203 | PN8109 | |
| 10.02~12.08 | 2000 | K20A7 | CM4 GR | RN1218VRN1405V | PN8485PN8125PN8465 | RN1203 | PN8398PN8109 | |
| 10.02~10.05 | 2000 | K20Z | CL7 LHD | RN1405VRN1204V | PN8125 | RN1203 | PN8109 | |
| 10.05~12.08 | 2000 | K20Z | CL7 LHD | RN1204VRN1405V | PN8125 | RN1203 | PN8109 | |
| 10.05~12.08 | 2000 | K20Z | CL7 RHD | RN1204V | PN8125 | RN1203 | PN8109 | |
| 06.06~12.08 | 2000 | K20Z2 | EURO | RN1204VRN1218V | PN8125PN8485 | RN1203 | PN8109PN8398 | |
| 01.98~01.03 | 2200 | H22A7 | CH1 | RN1248V | PN8254 | PN8109PN8398 | ||
| 09.97~01.02 | 2200 | H22A7 | EURO | RN1901V | PN8254 | PN8109 | ||
| 01.04~05.08 | 2200 | N22A1 | CN1 LHD | RN1204V | PN8125 | RN1203 | PN8109 | |
| 01.04~06.08 | 2200 | N22A1 | CN1 RHD | RN1204V | PN8125 | RN1203 | PN8109 | |
| 01.01~12.02 | 2300 | F23A1/3 | EURO | RN1248V | PN8484 | PN8109 | ||
| 01.01~12.02 | 2300 | F23Z5 | EURO | RN1137V | PN8465PN8106 | PN8109 | ||
| 10.02~12.08 | 2400 | K24A | CL9 JPN | RN1413VRN1204V | PN8465PN8125 | RN1203 | PN8398PN8109 | |
| 10.02~10.05 | 2400 | K24A3 | CL9 LHD | RN1413VRN1204V | PN8125PN8465 | RN1203 | PN8109PN8398 | |
| 10.05~12.08 | 2400 | K24A3 | CL9 LHD | RN1204V | PN8125 | RN1203 | PN8109 | |
| 10.02~12.08 | 2400 | K24A3 | CL9 RHD | RN1204VRN1413V | PN8125PN8465 | RN1203 | PN8109PN8398 |
