ROTOR DISC » RN1264V
A PHP Error was encountered
Severity: 8192
Message: Implicit conversion from float -209.5 to int loses precision
Filename: libraries/Image_lib.php
Line Number: 1230
Specification
Type
Vented
Disc Thickness (Max)
25
Num. of holes
6
Height
51.4
Centering Diameter
91
Pitch Circle Ø
120
Front/Rear
Front
Outter Ø
258
Drum Ø:
132
Disc Thickness (Min)
23
Structure Material
G3000
Cross Reference
TOYOTA
43512-25020
| years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 08.85~08.87 | 1600 | 1Y | YY50 | RN1264V | PN1212 | DN1251 | FN2260FN2276FN2275 | FN2298 |
| 08.87~09.93 | 1800 | 2Y | YY51 | RN1264V | PN1212 | DN1251 | FN2275FN2260FN2276 | FN2298 |
| 08.85~05.95 | 2000 | 3Y | YY52 | RN1264V | PN1212 | FN2275FN2260FN2286 | FN2298 | |
| 08.85~12.95 | 2000 | 3Y | YY61 | RN1264VRN1265V | PN1212 | FN2275FN2297 | FN2298 | |
| 08.87~05.95 | 2400 | 2L | LY50 | RN1264V | PN1212 | FN2276FN2260 | ||
| 08.85~08.88 | 2400 | 2L | LY60 | RN1264VRN1265V | PN1212 | FN2275FN2297 | FN2298 | |
| 05.95~05.99 | 2800 | 3L | LY201 | RN1264V | PN1212 | DN1251 | FN2260FN2286FN2275 | FN2298 |
| 11.85~05.95 | 2800 | 3L | LY51 | RN1264V | PN1212 | FN2286FN2275 | FN2298 | |
| 01.86~01.96 | 2800 | 3L | LY61 | RN1264V | PN1212 | FN2297FN2286 | FN2298 | |
| 05.99~07.01 | 3000 | 5L | LY212 | RN1264VRN1265V | PN1212 | FN2362FN2297FN2286 | FN2298 |
