BRAKE SHOE » FN2275
A PHP Error was encountered
Severity: 8192
Message: Implicit conversion from float -9.5 to int loses precision
Filename: libraries/Image_lib.php
Line Number: 1230
Specification
Radius
145
Width
60
Thickness
5.9/ 8.1
Pcs In Set
4
Cross Reference
AKEBONO
NR-1038
KASHIYAMA
K2275
TOYOTA
04494-25020
TOYOTA
04494-25050
TOYOTA
04494-25060
TOYOTA
04494-25080
TOYOTA
04496-25020
| years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 08.85~08.87 | 1600 | 1Y | YY50 | RN1264V | PN1212 | DN1251 | FN2260FN2276FN2275 | FN2298 |
| 08.87~08.88 | 1800 | 2Y | YY51 | RN1264V | PN1212 | DN1251 | FN2275FN2260FN2276 | FN2298 |
| 08.85~05.95 | 2000 | 3Y | YY52 | RN1264V | PN1212 | FN2275FN2260FN2286 | FN2298 | |
| 08.85~12.95 | 2000 | 3Y | YY61 | RN1264VRN1265V | PN1212 | FN2275FN2297 | FN2298 | |
| 08.85~08.88 | 2400 | 2L | LY60 | RN1264VRN1265V | PN1212 | FN2275FN2297 | FN2298 | |
| 10.96~05.99 | 2800 | 3L | LY121 | RN1358V | PN1237 | FN2275FN2286 | FN2300FN2298 | |
| 10.96~05.99 | 2800 | 3L | LY131 | RN1358V | PN1237 | FN2275FN2286 | FN2298 | |
| 05.95~05.99 | 2800 | 3L | LY201 | RN1264V | PN1212 | DN1251 | FN2260FN2286FN2275 | FN2298 |
| 11.85~05.95 | 2800 | 3L | LY51 | RN1264V | PN1212 | FN2286FN2275 | FN2298 | |
| 05.99~07.01 | 3000 | 5L | LY202 | PN1212 | FN2275 | FN2298 | ||
| 05.99~07.01 | 3000 | 5L | LY212L | PN1212 | FN2275FN2297 | FN2298 |
| 01.95~10.01 | 3000 | 5L-E | LY212R | RN1264VRN1265V | PN1212 | FN2275FN2286FN2297 | FN2298FN0015 | |
| 07.01~ | 3000 | 5L-E | LY235L | RN1264V | PN1237 | FN2275 | FN2298 | |
| 07.01~ | 3000 | 5L-E | LY235R | RN1264V | PN1237 | FN2286FN2275 | FN2298 |
| 10.96~07.01 | 2000 | 3Y | YY121 | RN1358VRN1535V | PN1237 | FN2275FN2286 | FN2298 | |
| 10.96~07.01 | 2000 | 3Y | YY131 | RN1358VRN1535V | PN1237 | FN2275FN2286 | FN2300FN2298 | |
| 05.95~07.01 | 2000 | 3Y | YY201 | RN1264V | PN1212 | DN1251 | FN2260FN2286FN2275 | FN2298 |
| 05.95~07.01 | 2000 | 3Y | YY211 | RN1264V | PN1212 | FN2275FN2286 | FN2298 | |
| 05.95~05.99 | 2800 | 3L | LY211 | RN1264VRN1265V | PN1212 | FN2275FN2297FN2286 | FN2298 |
