ROTOR DISC » RN1358V
A PHP Error was encountered
Severity: 8192
Message: Implicit conversion from float -123.5 to int loses precision
Filename: libraries/Image_lib.php
Line Number: 1230
Specification
Type
Vented
Disc Thickness (Max)
22
Num. of holes
6
Height
52
Centering Diameter
100
Front/Rear
Front
Pitch Circle Ø
127.5
Outter Ø
287
Disc Thickness (Min)
20
Drum Ø:
153.7
Structure Material
G3000
Cross Reference
TOYOTA
43512-26081
| years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 10.96~05.99 | 2800 | 3L | LY121 | RN1358V | PN1237 | FN2275FN2286 | FN2300FN2298 | |
| 10.96~05.99 | 2800 | 3L | LY131 | RN1358V | PN1237 | FN2286FN2275 | FN2298 |
| 10.96~05.99 | 2000 | 3Y | YY121 | RN1535VRN1358V | PN1237 | FN2275FN2286 | FN2298 | |
| 10.96~05.99 | 2000 | 3Y | YY131 | RN1358VRN1535V | PN1237 | FN2286FN2275 | FN2298FN2300 | |
| 10.96~05.99 | 2800 | 3L | LY151 | RN1358V | PN1237 | DN1214 | FN2305 | |
| 10.96~05.99 | 2800 | 3L | LY161 | RN1358V | PN1237 | DN1214 | FN2305 |
| 01.84~12.89 | 2400 | 2L | LH66LV | RN1358V | PN1237 | DN1214 | FN2305 | |
| 08.86~08.89 | 2400 | 2L | LH66V | RN1358V | PN1237 | FN2305 | ||
| 08.87~05.95 | 2400 | 2L | LH85 | RN1358V | PN1237 | DN1214 | FN2305 | |
| 09.91~05.95 | 2400 | 2L | LH95 | RN1358V | PN1237 | FN2305 | ||
| 01.95~10.96 | 2800 | 3L | LY151 | RN1358V | PN1237 | DN1107DN1214 | FN2305FN2260 | |
| 04.95~10.96 | 2800 | 3L | LY161 | RN1358V | PN1237 | DN1107DN1214 | FN2260FN2305 |
