ROTOR DISC » RN1764V
A PHP Error was encountered
Severity: 8192
Message: Implicit conversion from float -473.5 to int loses precision
Filename: libraries/Image_lib.php
Line Number: 1230
A PHP Error was encountered
Severity: 8192
Message: Implicit conversion from float -117.5 to int loses precision
Filename: libraries/Image_lib.php
Line Number: 1230
Specification
Type
Vented
Outter Ø
300
Num. of holes
5
Disc Thickness (Max)
20
Height
50.6
Centering Diameter
67
Pitch Circle Ø
112
Front/Rear
Rear
Hole Ø:
16.7
Disc Thickness (Min)
18.4
Drum Ø:
166
Structure Material
G3000
Cross Reference
BMW
34 20 6 891 086
BMW
34 21 6 799 369
| years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 10.19~03.23 | 1500 | B38A15A | AK0 RHD | RN2057V | PN0577PN0672PN0573 | RN2058RN1764V | PN0651 | |
| 11.19~10.24 | 1500 | B38A15A | F44 | RN2057V | PN0577PN0672 | RN2058RN1764V | PN0651 |
| 07.20~10.24 | 2000 | B46A20B | F44 | RN1763V | PN0577PN0672 | RN1764V | PN0651 | |
| 07.20~10.24 | 2000 | B48A20A | F44 | RN1763V | PN0577PN0672 | RN1764V | PN0651 |
| 07.15~06.22 | 2000 | B47C20A | F48 | RN1763V | PN0577 | RN1764V | PN0651 | |
| 11.22~ | 2000 | B47C20B | U11 | RN2062VRN2057V | PN32011PN32012 | RN1764V | PN32010 |
| 07.15~06.22 | 2000 | B48A20A | F48 | RN1763V | PN0577 | RN1764V | PN0651 | |
| 07.22~ | 2000 | B48A20P | U11 | RN2062VRN2057VRN1763V | PN32011PN0577PN32012 | RN2058RN1764V | PN32010 |
| 07.15~06.19 | 2000 | B46A20B | F48 | RN1763V | PN0577 | RN1764V | PN0651 | |
| 06.19~10.22 | 2000 | B46A20B | HT11 US | RN1763V | PN0577 | RN1764V | PN0651 |
