ROTOR DISC » RN2057V
A PHP Error was encountered
Severity: 8192
Message: Implicit conversion from float -486.5 to int loses precision
Filename: libraries/Image_lib.php
Line Number: 1230
Specification
Type
Vented
Outter Ø
307
Num. of holes
5
Disc Thickness (Max)
24
Height
45
Centering Diameter
67
Pitch Circle Ø
112
Drum Ø:
151
Disc Thickness (Min)
22.4
Structure Material
G3000
Cross Reference
BMW
34 10 6 891 079
BMW
34 10 6 897 426
BMW
34 11 6 799 351
BMW
34 11 6 860 957
| years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 11.18~12.22 | 1500 | B38A15 | F46 | RN2057V | PN0577PN0573 | RN2058 | PN0651 | |
| 03.15~03.18 | 1500 | B38A15A | F46 | RN2057V | PN0577 | RN2058 | PN0651 |
| 11.21~ | 1500 | B38A15 | U06 | RN2057V | PN32011 | RN2058 | PN32010 | |
| 07.14~06.16 | 1500 | B38A15A | F45 | RN2407VRN2057V | PN0577PN0573 | RN2058 | PN0651 |
| 10.19~03.23 | 1500 | B38A15A | AK0 RHD | RN2057V | PN0577PN0672PN0573 | RN2058RN1764V | PN0651 | |
| 11.19~10.24 | 1500 | B38A15A | F44 | RN2057V | PN0577PN0672 | RN2058RN1764V | PN0651 |
| 07.15~06.22 | 2000 | B47C20A | F48 | RN2057V | PN0577 | RN2058 | PN0651 | |
| 07.22~ | 2000 | B47C20B | U11 | RN2057V | PN32011 | RN2058 | PN32010 |
| 11.15~06.22 | 1500 | B38A15A | F48 | RN2057V | PN0577 | RN2058 | PN0651 | |
| 07.17~06.22 | 1500 | B38A15A | F48 | RN2057V | PN0577 | RN2058 | PN0651 |
| 07.15~06.22 | 2000 | B47C20A | F48 | RN2057V | PN0577PN0573 | RN2058 | PN0651 | |
| 10.19~02.23 | 2000 | B47C20B | 32AD JPN RHD | RN2057V | PN0577PN0573 | RN2058 | PN0651 |
| 03.18~ | 1500 | B32S15A | F39 | RN2057V | PN0577PN0573 | RN2058 | PN0651 | |
| 10.17~10.23 | 1500 | B38A15 | YH12 RHD | RN2057V | PN0577PN0573 | RN2058 | PN0651 | |
| 03.18~ | 1500 | B38A15A | F39 | RN2057V | PN0577PN0573 | RN2058 | PN0651 |
| 11.17~06.20 | 2000 | B47C20A | F39 | RN2057V | PN0672PN0577 | RN2058RN1764V | PN0651 | |
| 11.17~ | 2000 | B47C20B | F39 | RN2057V | PN0672PN0577 | RN2058RN1764V | PN0651 |
